Mobile qso with Mohammed 7X4AN

-

.
I regulary Work 7X4AN Mohammed on 20m from my Mobile Station which comprises of Yaesu's Field Commando the mighty FT100,50watts and the amazing Maldol 20m hfc whip.

I have worked 7X4AN at least 20 times from my mobile usually travelling back and forth on my work journey..Many thanks Mohammed I look forward to our next QSO
ma salam a 73
