A Fun Day Had By All

-
Sunday was a fun day for Yorkshire Radio Ham's M1PAC - Phil, M6AXL -Adam, M3TLL - Louise and myself 2E0HTS - Simon.
Adam and Phil set up their station early Sunday morning up on Rombalds moor which is high up out in the sticks near to our QTH. They were running QRP and worked through plenty of pile ups on the 144 SSB portion of the VHF bands.

Louise and I joined them in the afternoon and worked one or two nice contacts on HF which included the previously mentioned CRAG CASHOTA activation at Elslack operated by MX0BCQ/p with Kevin - M0XLT at the controls.
Our Portable/Mobile QTH
Adams New Beast of a Beam with Human Rotator Phil
Phil, Adam & Louise
The Yorkshire Moor Top Ham Brigade!

Check out the action and signals/stations worked on the video, including M0YCM-Les, G4JNN-Paul, 5D0IPY-Rachid & MX0BCQ/P-Kevin.
