40/80 FAN Dipole Test

-

I have been wanting to try something new for 40m and today I decided to add two elements cut for 40 meters to my 80 meter mono band dipole making it a FAN Dipole.
The end result for today was, the 40/80m Fan dipole is resonant without an ATU on both bands and works very well on my first test. I put a video together operating on 80m using 50 watts during a RSGB 80m contest. I wanted to be sure that the extra elements would not have any detrimental effects on the performance on 80m. I found that the low power did not matter the dipole is still working really well on 80m. I checked it on 40m and I heard signals slightly stronger with the new Fan dipole over the vertical. Japan was coming in very well and later I made a nice QSO using the Fan dipole on 40m with VE9FI - Russ over in Canada. A good result so far!

Sizes of each leg is 80m - 2 x 67 ft lengths and 40m - 2 X 33 ft lengths.

Here is the video which will help you to pass 20 minutes, Stay Safe! Stay In! Save Lives!
