Satellite SSB DX with RS-44

-


I finally got around to adjusting the UP-link on the SatPC32 software. It now matches the Doppler correction required to operate the SSB Transponder much easier with less adjustments whilst in QSO..

RS-44 Russian Sputnik Satellite.
A couple more contacts made and a final Doppler adjustment made towards the end of the pass. Now I am bang on frequency. Every radio differs slightly when setting up SatPC32 pre configured settings for the up link and down link. Careful adjustments using the CAT tab can be made when the pass is nice and clear. This helps to save time next time I use this bird as I will not require further fine tuning and will have a better copy. 73 thanks for following! I hope you have fun on the Satellite bands!
